Reach Trucks

COMFORT | • All movements of the fork can be regulated with stepless speed. This provides more accurate and stable handling of goods. • The imported tiller’s function buttons are designed to allow the operator to comfortably operate the stacker. • The standard configuration creep speed driving function allows the truck to move at slow speeds. This increases the stacker’s maneuverability and allows it to stack goods even in confined spaces. • The stacker’s compact body and large rounded corner design make the truck perfect for narrow aisle operation. • The optional battery side roll out makes swapping out the battery fast and easy.

HIGH PERFORMANCE | • The Electric Power Steering (EPS) system makes maneuvering and load handling extremely easy. • The brushless AC travel motor features excellent acceleration, outstanding climbing ability, low heat emission, and is maintenance-free. • The latest CURTIS AC control system is highly efficient thanks to its accurate and stable control. • The CANBUS structure makes communication between all of the machine’s functions faster and more reliable. • The truck’s regenerative braking prevents it from sliding on a grade. • Tiller, switches, plug connectors, meters, and other components are all parts from industry-known suppliers to ensure reliability, performance, and ease of service. • The forks and load backrest have a backward and forward tilt function as a part of the standard configuration. This creates a safer experience when loading and unloading goods.

RELIABILITY | • The three-support-point, low center of gravity, and the high-strength steel plate structure feature a large residual load-bearing capacity and a long service life. • All wires and cables are protected to increase the reliability of the electrical system significantly. • The non-contact proximity switch features a long service life and is reliable. • The power plug is fastened to the stacker’s body. This prevents the plug from being damaged due to impact when the battery is lifted for install

SAFETY | • As the truck’s steering angle increases, the truck’s speed decreases. This is a standard safety feature. • The reach stacker features three types of braking functions, release braking, reverse braking, and emergency braking, for safe operation. • The anti-sliding function on a grade ensures a safe operational workspace. • The emergency reversing button at top of the tiller protects the operator from being injured in case of an emergency during the backward operation of the truck. • The soft-landing function reduces the mast’s lowering speed automatically when the forks are lowered to a height less than 3.9” from the ground. This is designed to protect the goods from hitting the ground too hard.

Change Your Preferred Location

DIMENSIONS - Length:	74.8 in
DIMENSIONS - Overhead Guard Height:	95 in
DIMENSIONS - Wheelbase:	58 in
PERFOMANCE - Lift Speed - Loaded:	69 ft/min

capacity:	4000
capacityUnit:	pound
DIMENSIONS - Length:	74.8 in
DIMENSIONS - Overhead Guard Height:	95 in

Base Leg Outside Dimension:	52.5-64 in.
Length to Fork Face:	67.2-74.3 in.
Lifting Capacity:	3,200-4,500 lb. Lifting Capacity
Load Center:	24 in. Load Center

Electrical System:	48V Electrical System
Length to Fork Face:	52.9 in.
Lift Height:	295" Lift Height
Lifting Capacity:	3,500 lb. Lifting Capacity

Electrical System:	48V Electrical System
Length to Fork Face:	49.7-62 in.
Lift Height:	512 in. Lift Height
Lifting Capactiy:	5,500 lb. Lifting Capactiy

Base Leg Outside Dimension:	75.5 in.
Length to Fork Face:	56.3-61.3 in.
Lifting Capacity:	4,500 Lifting Capacity
Load Center:	24 in. Load Center

Length to Fork Face:	55.3 - 67 in
Load Capacity:	2,500 - 4,500 lb. Load Capacity
Mast Lowered Height:	89 - 135 in
Maximum fork height:	Up to 30.5 feet Maximum fork height

Battery Charger:	48V/65A 220V 3 Phase Charger / 48V/80A 220V 3 Phase Charger
Fork Dimensions:	42" Standard
Load Capacity:	3,500 / 4,500lb
Load Center:	24"

Length to Forkface:	47.4 - 50.6 in
Load Capacity:	3,000 lb. Load Capacity
Mast Lowered Height:	83 in
Overall Width:	40 - 58 in
